Description du produit
Type; four-wheel drive
Overall dimensions (length x width x height); 3800x1620x2200 mm
Wheelbase or track grounding length; 2100 mm
Track gauge (front/rear wheels) or track gauge; 1260/1280 mm
Adjustment method for wheelbase (front/rear wheels); Adjustable with levels/Adjustable with levels
Minimum ground clearance; 320 (middle of front axle lower edge) mm
Minimum usage quality; 2500 KG
Front axle mass/rear axle mass; 1038/1462 KG
Maximum counterweight (front/rear); 144/360 KG
Gear forward/reverse/crawl; 8/8
Theoretical speed of each gear;
Forward: 2.61, 3.68, 5.04, 7.75, 6.59, 9.2612.70, 19.53, 11.32, 15.92, 21.84, km/h33 59 Backward: 2.29, 3.22, 4.42, 6.80, 5.77, 8.1211.13, 17.12, 9.93, 13.96, 19.14, 29.44
Connection method between engine and clutch; direct connection
Starting method; electric start
Power output shaft power; 43.8kW
Maximum traction force; 16.5 KN
